Linear Conveyor Mudule LCMR200
Yamaha’s answer to the Next Generation of Production Line design.
Convert transfer process into “value-added” assembly process.
Max. Speed: 2500mm/sec
Repeatability: ±5μm
Max. Payload: 30 Kg
Max. Acceleration: 1.3G
– All the sliders can be operated /programmed independently.
– High acceleration rate
– Mechanical tolerance between sliders +/-30 µm (Dowel hole standard)
– Built-in driver saves electrical wiring
– No origin process needed
– Optimal for traceability management
– Variable speed control between work stations.
– Assembly can be done while parts are on the conveyor
